How Does TIREBOSS Benefit You?
Reduced tire pressure provides extremely low ground pressure and incredible mobility. Maximum tire pressure (eg 100 psi) is only required when the vehicle is fully loaded at highway speeds.
A reduction in vehicle load or speed allows for a safe reduction in tire pressure with a multitude of benefits.
Create a longer footprint and larger contact surface area with TIREBOSS.
Additional Benefits:
Improved truck efficiency
Increased tire life
Fewer lost time incidents & towing costs
Improved site access
Reduction in damage to work sites & roadways
Reduced vibration damage
Improved fuel economy
Providing a cost-effective alternative to all-wheel drive
TIREBOSS 2 Features
Operator video embedded in controller
Interactive touch screen display
GPS Speed monitoring of reduced tire pressures with auto inflate if speed exceeded
Instantaneous warning of tire pressure loss
Dual protection of air brake system
Automatic wheel end lock valves at each wheel
Wi-Fi capable for data transfer and program updates
Multi-language display capable
Adaptable to all axle, wheel and truck types
Transferable from vehicle to vehicle
Fast inflation and deflation times
Control of 1-4 separate tire groups
Self-diagnostic components
Software varies pressure for normal tire heat build-up
Settings adjustable on controller with fleet manager access (p/w protected)
Heated control valves for cold weather operation
Interface capability to on-board Data-Log computers
Black Box data recorder for critical operation analysis
Specifications
Control valve air flow capacity up to 75 CFM (2124 L/min.)
11v to 36v power circuits
Designed for -40° to 125°F operating temperature
RS485 serial interface for control system (CAN bus capable)
RS232 serial interface or USB for external data loggers
Tire pressure control accuracy within a nominal range of +/- 2 psi of actual tire pressure
Basic system weight: One valve-Single Axle 100 lbs (45 kg)
One valve-Tandem Axle 145 lbs (65 kg)
